ELECTROGARD EXPOSIL

Two Component Epoxy based Dielectric Insulation Floor Coating

ELECTROGARD EXPOSIL

Overview

ELECTROGARD® Exposil is a high performance solvent free two component Electric Insulation floor and coating for exposed area. It provides a hard wearing floor/wall finish for use in most industrial and commercial premises where a high voltage resistance floor/wall is required.

For More Info call us: +91-9323890195 Contact
  • Advantage
  • Specification Clause
  • Technical Data
  • Project Profile
  • Download

Advantage

  • High dielectric strength and insulation resistant
  • High bond strength
  • Less than 0.1% porosity
  • Seamless and hygienic surface
  • Abrasion resistance
  • Easy to apply being composite pack.

Specification Clause

  • Thickness: 150 to 200µm
  • Bond Strength: >1.5 MPa (Concrete Breaks)
  • Shore D Hardness: 85-88
  • Touch Dry Time: 2-5 Hours
  • Min. Working Temperature: 25°C
  • Coverage, Kg/m2/150 µm: 0.28
  • Compressive Strength: >50 N/mm2
  • Flexural Strength: >48 N/mm2

Technical Data

  • Uses: Electrical & electronics facilities, control panel rooms, transformer rooms, LT/HT laboratories, Industrial plants, Metal-treatment plants, production areas, Waste & utility areas
  • Colour Available: Blue, Green, Signal Yellow, Dark Red
  • Method of Application: Brush, trowel or roller at desired thickness
  • Packing: 20 Kg composite pack

Project Profile

Project profile coming soon !

Download

To access TDS, click here
